Specifications Met:

D.O.T. 49 CFR 571.106, SAE J844

Application:

Transportation, Air Brake

Tube Inside Diameter:

6.4 mm, 0.251 inch

Tube Outside Diameter:

9.5 mm, 0.375 inch

Color:

Red

Tube O.D. (inch):

3/8

Maximum Operating Pressure:

150 psi, 10.3 bar

Minimum Burst Pressure:

1400 psi, 96.5 bar

Maximum Operating Temperature:

200 °F, 93 °C

Minimum Operating Temperature:

-40 °F, -40 °C

Minimum Bend Radius:

1-1/2 inch, 38.1 mm

Compatible Fitting:

NTA®, Air Brake, Prestomatic, SAE Cartridges, PTC

Media:

Air

Weight:

0.027 lb/ft, 0.04 kg/m

Tube Material:

Polyamide (PA) Fiber Reinforcement

Product Type:

Reinforced

Cover Color:

Red

Color:

Red

Size:

-6

Cover Material:

Polyamide (PA)

Standard Pack Qty (ft):

500
